Camera Image Sensor 5 MP CMOS Signal System PAL / NTSC Resolution 2560 (H) × 1944 (V) Frame Rate TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps CVI: 4MP@30fps, 4MP@25fps AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL / NTSC Min. illumination 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR Shutter Time PAL: 1 / 25 s to 1 / 50, 000 s NTSC: 1 / 30 s to 1 / 50, 000 s Lens 2.8 mm Field of View Horizontal FOV: 85.5°, Vertical FOV: 63.7°, Diagonal FOV: 110.7° Lens Mount M12 Day & Night ICR WDR (Wide Dynamic Range) Digital WDR Audio Built-in mic Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360° Menu Image Mode STD / HIGH-SAT AGC Yes Day / Night Mode Auto / Color / BW (Black and White) White Balance Auto / Manual AE (Auto Exposure) Mode DWDR / BLC / HLC / Global Noise Reduction 2D DNR Language English Function Brightness, Sharpness, Mirror, Smart IR Interface Video Output Switchable TVI / AHD / CVI / CVBS General Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing) Power Supply 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. Power Consumption Max. 3.7 W Material Plastic IR Range Up to 20 m Communication HIKVISION-C Dimensions Φ 84.6 mm × 78.9 mm (Φ 3.33″ × 3.11″) Weight Approx. 140.5 g (0.31 lb.)
