Camera Image Sensor 5MP CMOS Signal System PAL/NTSC Resolution 2560 (H) × 1944 (V) Frame Rate TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps CVI: 4MP@30fps, 4MP@25fps AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL/NTSC Min. illumination 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR Shutter Time PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s Lens 2.8 mm, 3.6 mm, 6 mm fixed lens Field of View 3.6 mm, horizontal FOV: 80.1°, vertical FOV: 63.7°, diagonal FOV: 105.9° Lens Mount M12 Day & Night ICR WDR (Wide Dynamic Range) Digital WDR Audio Built-in Microphone Angle Adjustment Pan: 0 to 355°, Tilt: 0 to 75°, Rotation: 0 to 355° Menu Image Mode STD/HIGH-SAT AGC Yes Day/Night Mode Auto/Color/BW (Black and White) White Balance Auto/Manual AE (Auto Exposure) Mode DWDR / BLC / HLC / Global Noise Reduction 2D DNR Language English Function Brightness, Sharpness, Mirror, Smart IR Interface Video Output Switchable TVI / AHD / CVI / CVBS General Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing) Power Supply 12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera. Power Consumption Max. 3.7 W Protection Level IP67 Material Plastic
