Vertical engagement lock system SnapBee™

$68.47 $134.21
Series ​​ ​​ ​​ ​​ ​​ ​​ Pitch 1.2mm 1.2mm(Middle Pin of 3pos. Removed : 32.4mm) 1.7mm 2.2mm 2.2mm 2.0mm(Middle Pin of 3pos. Removed : 4.0mm) No. of Pos. 2 - 4, 6 2 - 6 3 - 7 2, 3 2 2 - 4 Size Height 1.0mm 1.4mm(26 AWG: 1.6mm) 1.8mm 2.0mm 2.38mm 2.48mm Depth 4.97mm 4.65mm 6.05mm, 6.1mm 7.35mm 7.35mm 8.15mm Rating RatedCurrent 3A Max. 3A Max. 4A Max. 4A Max. 5A Max. 3A Max. RatedVoltage 100V AC/DC 50V AC/DC(Middle Pin of 3pos.Removed : 3A) 50V AC/DC 350V AC/DC 350V AC/DC 230V AC/DC Applicable Cable 28 - 30 AWG 26 - 34 AWG 24 - 28 AWG 24 - 28 AWG 22 - 28 AWG 22 AWG Lock Type ViSe Swing ViSe ViSe Swing Swing
