Cable connector with board

Series name Contact Pitch Number of Pins Rated current Safety standard Features 1 Row 2 Rows 2 Pins 3 Pins UL C-UL/CSA TÜV DF3 2mm 2,3,4,5,6,7,8,9,10, 11,12,13,14,15 - 1A/pin 1A/pin 〇 〇 - Friction Lock DF11 2mm - 4,6,8,10,12,14,16, 18,20,22,24,26,28, 30,32 1A/pin 1A/pin 〇 〇 - Friction Lock DF13 1.25mm 2,3,4,5,6,7,8,9,10, 11,12,13,14,15 10,20,30,40 2A/pin 1A/pin 〇 - - Friction Lock DF14  1.25mm 2,3,4,5,6,7,8,9,10, 15,20,25,30 - 1A/pin 1A/pin - - - Friction Lock DF19  1mm  8,14,20,30 - 1A/pin 1A/pin - - - Friction Lock DF20  1mm  - 10,20,30,40,50 1A/pin 1A/pin - - - Friction Lock DF50 1mm 2,3,4,5,6,7,8,9,10, 11,12,13,14,15,16  20,30,40,50 2A/pin 1A/pin - - - Positive Lock DF52 0.8mm 2,3,4,5,6,8,10, 12,14,15,16,17,20  - 2.5A/pin 2A/pin - - - Friction Lock DF57  1.2mm 2,3,4,5,6  - 2.5A/pin 2A/pin 〇 〇 - Swing Lock DF58  1.2mm 2,3,4,6  - 3A/pin 2.5A/pin - - - Vise Lock DF61  2.2mm 2  - 3A/pin - 〇 〇 - Swing Lock DF61Y  2.2mm 2 - 3A/pin - - - - Vise Lock DF65  1.7mm 3,4,5,6,7 - 3A/pin - 〇 〇 - Vise Lock KW30  1mm 2,3,6,7,8,10,15 - 3A/pin 1A/pin 〇 〇 - Positive Lock
