DISPLAY Panel Technology PLS TFT with W-LED backlight Screen Size [inch/cm] 27 / 68 Screen Aspect Ratio 16:9 Colour Gamuts 100 % sRGB; 75 % NTSC Pixel Pitch [mm] 0.233 Brightness (typ.) [cd/m²] 350 Contrast Ratio (typ.) 1000:1 (7000:1 dynamic contrast ratio) Viewing Angle [°] 178 horizontal / 178 vertical (typ. at contrast ratio 10:1) Response Time (typ.) [ms] 6 Colours [Mio.] 16.78 SYNCHRONISATION RATE Horizontal Frequency [kHz] 31.5 – 94 Vertical Frequency [Hz] 56 – 75 RESOLUTION Optimum Resolution 2560 x 1440 at 60 Hz Supported 2560 x 1440;1920 x 1440;1920 x 1080;1600 x 1200;1280 x 1024;1152 x 864;1024 x 768;832 x 624;800 x 600;640 x 480 CONNECTIVITY Digital 1 x DisplayPort; 1 x DisplayPort out; 1 x HDMI; 1 x USB Type C (60 W); 1x DVI-D (Dual Link); USB ver. 3.1 (3 down / 2 up) ELECTRICAL Power Consumption on Mode [W] 150 (max.); 30 (Eco Mode 2); 37 (Eco Mode 1); 37 (shipping); 37 (typ.) Power Savings Mode [W] 0.35 Power Supply 0.75 A/1.6 A; 100-240 V; internal power supply ENVIRONMENTAL CONDITIONS Operating Temperature [°C] 5 to 35 Operating Humidity [%] 20 to 80 Storage Humidity [%] 10 to 85 Storage Temperature [°C] -10 to 60 ERGONOMICS Height adjustable stand [mm] 150 Screen Tilt [°] -5 to 35 Screen Swivel [°] -170 to 170 Screen Rotate [°] -90 to 90 (landscape to portrait mode) MECHANICAL Bezel Width [mm] 1 (left/right/top) Dimensions (W x H x D) [mm] 361.9 x 628.6 – 652.1 x 250 (Portrait mode); 611.8 x 378 – 528 x 250 (Landscape mode) Weight [kg] With stand: 9.1; Without stand: 5.7 VESA Mounting [mm] 100 x 100 ADDITIONAL FEATURES Special Characteristics Ambient light sensor for optimized brightness levels; Carbon Footprint Meter; Carbon Savings Meter; ControlSync®; Customize Setting; DisplayPort; EcoModes; ErgoDesign®: Height adjustable stand (150 mm) with 90° Pivot features; Human Sensor; LED Backlight Technology; NaViSet Administrator 2; Picture-by-Picture; Quick release Stand and Handle; TileMatrix; Touch Sensor Keys; USB ver. 3.1 (3 down / 2 up); Versatile and easy installation (VESA standard) with NaViSet and NaViKey Colour Versions Black Front Bezel, Black Back Cabinet; White Front Bezel, White Back Cabinet Cable Management yes Kensington security slot yes Plug and Play DDC2B/2Bi; EDID Standard; VESA DDC/CI Audio 1W 1W (De-activateable); Headphone Jack Adjust Functions Audio Volume / Lock-Out; Auto Adjust; Brightness; Colour Temperature Control; Contrast; Control Sync; DV Mode; EcoMode; Human Sensing; Intelligent Power Management; Language Select; Monitor Information; On-Screen-Display (OSD) lock-out; One Touch Recovery; Power-Off Timer Shipping Content Control Sync Cable; DisplayPort cable; Monitor; Power Cable; Setup Guide; USB Cable Safety and Ergonomics CE; EAC; ErP; ISO 9241-307 (pixel failure class I); PSB; RoHS; TCO 7.0; TCO Certified Edge Displays 1.2.; TÜV Ergonomics; TÜV GS; UL/C-UL or CSA Warranty 3 years warranty incl. backlight; optional 4th to 5th year warranty extension GREEN FEATURES Energy Efficiency Ambient light sensor; ECOMode; Energy efficiency class: A; Human sensor Ecological Materials Minimal use of harmful material Ecological Standards Energy Star 7.1; ErP compliant; RoHS compliant; TCO 7.0; TCO edge
