FPC/FFC Connector Select Map

Standard eDP ver1.3HBR100Ω MIPI D-PHYver1.2100Ω PCI ExpressGen285Ω PCI ExpressGen385Ω USB3.2Gen190Ω USB3.2 Gen2(Type-C)85Ω FH55 GSSG High Speed Transmission ✓ ✓ ✓ ✓ ✓ ✓ FH34SRJ/D GSSG Standard Product (0.5mm Pitch) ✓ ✓ ✓ ✓ ✓ ✓ FH41 GSGSG AutomotiveCompatible with Shielded FFC ✓ ✓ ✓ ✓ ✓ - FH52K GSGSG Automotive Standard Product (0.5mm Pitch) ✓ ✓ ✓ ✓ ✓ - FH64MA GSGSG Low Profile ✓ ✓ ✓ ✓ ✓ - FH58 GSGSG Narrow Pitch (0.2mm Pitch) ✓ ✓ ✓ - ✓ - FH65 GSSG Automotive, Low Profile - ✓ ✓ ✓ ✓ - FH48 GSGSG Vertical ConnectionShielded FFC ✓ ✓ - - ✓ - FH35CGSGSG Standard Product(0.3mm Pitch) ✓ ✓ - ✓ - -
